Temperature

+25°C

-20°C

+70°C

Output Frequency

14500 MHz

14501.3

14501.64

14501.14

Output Power

+13 dBm min

15

14.9

15.1

Output Power Variation

2 dBm/°C Over Temp. Range

<2

<2

<2

Harmonics

-20 dBc max

-30

-28

-33

Spurious

-80 dBc max

< -80

< -80

< -80

Mechanical Tuning

+/- 10 MHz min

+/- 20

+/- 20

+/- 20

Frequency Pushing

20 kHz/V max

10

10

10

VSWR

1.5:1

< 1.5

< 1.5

< 1.5

Frequency Pulling

5 MHz P-P max

< 5

< 5

< 5

Phase Noise

-80 dBc/Hz @ 10 K offset

-84

-85

-86

DC Voltage

+15 Vdc

+15

+15

+15

DC Current

120 mA max

130

130

130

Connector

SMA-Female

SMA-Female

SMA-Female

SMA-Female

Temperature Range

-20°C ~ 70°C

-20°C ~ 70°C

-20°C ~ 70°C

-20°C ~ 70°C
